Kioxia Exceria Plus G4 2TB NVMe PCIe 5×4 SSD – LVD10Z002TG8

EXCERIA PLUS G4 SSD Product Specifications

Capacity / dimensions

• Capacity : 1TB, 2TB

• Form Factor : M.2 Type 2280-S3-M

• Interface : PCI Express® Base Specification Revision 5.0 (PCIe®)

• Flash Memory type : BiCS FLASH™ TLC

• Interface Maximum Speed : 128 GT/s (PCIe® Gen5x4)

• Dimension (Max: LxWxH) : 80.15 x 22.15 x 2.38 mm

• Interface Protocol : NVM Express™ Base Specification 2.0c

• Weight :

  1TB: 5.6 g (typ.)
  2TB: 5.7 g (typ.)

Performance

• Max Sequential Read Speed*1 : 10,000 MB/s

• Max Sequential Write Speed*1 :

  1TB: 7,900 MB/s
  2TB: 8,200 MB/s

• Max Random Read Speed*2 :  1,300,000 IOPS

• Max Random Write Speed*2 : 1,400,000 IOPS

• Endurance: TBW*3 :

  1TB: 600 TB
  2TB: 1,200 TB

• MTTF : 1.5 million hours

Operating environment / protection performance

• Operating Temperature : 0 ℃ (Ta) to 85 ℃ (Tc)

• Storage Temperature : -40 ℃ to 85 ℃

• Certification : RoHS compliant*5

• Shock Resistance : 9.806 km/s2 {1,000 G} 0.5 ms half sine wave

• Vibration : 25.4mm peak-to-peak (10Hz to 20Hz), 20G peak (20Hz to 2000Hz), (20min /Axis) x 3 Axis

• Supply Voltage : 3.3 V ±5 %

• Power Consumption :

  PS3: 50 mW (typ.)
  PS4: 5 mW (typ.)

• Power Consumption (Active) : 5.3 W (typ.)

Compatibility

• Connector Type : M.2 M key Socket

• Target Applications : Client desktops and laptops

Others

• Services and Support : Up to 5-year manufacturer's warranty*4

• Performance Optimization : TRIM, Idle Time Garbage Collection, Host Memory Buffer

Product Info

• 1TB :

  PN: LVD10Z001TG8
  EAN: 4582563859975

• 2TB :

  PN: LVD10Z002TG8
  EAN: 4582563859982
