Picture/Display
LCD panel type
IPS technology
Adaptive sync
Yes
Backlight type
W-LED system
Panel Size
23.8 inch / 60.5 cm
Display Screen Coating
Anti-Glare, 3H, Haze 25%
Effective viewing area
527 (H) x 296.5 (V)
Aspect ratio
16:9
Maximum resolution
1920 x 1080 @ 75 Hz*
Pixel Density
93 PPI
Response time (typical)
4 ms (GtG)*
Brightness
250 cd/m²
Contrast ratio (typical)
1000:1
SmartContrast
Mega Infinity DCR
Pixel pitch
0.275 x 0.275 mm
Viewing angle
178º (H) / 178º (V)
@ C/R > 10
Flicker-free
Yes
Display colors
16.7 M
Scanning Frequency
30 -83 kHz (H) / 56 -76 Hz (V)
LowBlue Mode
Yes
EasyRead
Yes
sRGB
Yes
Connectivity
Signal Input
VGA (Analog )
HDMI (digital, HDCP)
Sync Input
Separate Sync
Sync on Green
Audio (In/Out)
HDMI audio out
Other convenience
Kensington lock
VESA mount (100x100mm)
Plug & Play Compatibility
DDC/CI
Mac OS X
sRGB
Windows 10 / 8.1 / 8 / 7
Stand
Tilt
-5/20 degree
Power
On mode
19.9 W (typ.)
Standby mode
0.5 W (typ.)
Off mode
0.3 W (typ.)
Power LED indicator
Operation – White
Standby mode- White (blinking)
Power supply
Built-in
100-240VAC, 50-60Hz
Dimensions
Product with stand (mm)
540 x 416 x 220 mm
Product without stand (mm)
540 x 322 x 51 mm
Packaging in mm (WxHxD)
600 x 420 x 133 mm
Weight
Product with stand (kg)
3.06 kg
Product without stand (kg)
2.66 kg
Product with packaging (kg)
4.31 kg
Operating conditions
Temperature range (operation)
0°C to 40°C °C
Temperature range (storage)
-20°C to 60°C °C
Relative humidity
20%-80 %
Altitude
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
MTBF
50,000 (Excluded backlight) hour(s)
Sustainability
Environmental and energy
RoHS
Lead-free
Mercury Free
Recyclable packaging material
100 %
Compliance and standards
Regulatory Approvals
CECP
CCC
CEL
Cabinet
Color
White
Finish
Textured
