Specifications
Picture/Display
Panel Size: 23.8"/60.5 cm
Aspect ratio: 16:9
LCD panel type: IPS
Backlight type: W-LED system
Pixel pitch: 0.2058 (H) x 0.2058 (V)mm
Brightness: 300 cd/m²
Display colors: 16.7 M
Color gamut (typical): Adobe RGB 92.9%; DCIP3:94%, sRGB: 120%, NTSC 104%,*
Contrast ratio (typical): 1500:1
SmartContrast: Mega Infinity DCR
Response time (typical): 4 ms (Gray to Gray)*
Viewing angle: 178º (H) / 178º (V), @ C/R > 10
Picture enhancement: SmartImage game
Maximum resolution: 1920×1080 @ 144Hz
(HDMI)
Effective viewing area: 527.04(H)x296.46(V)mm
Scanning Frequency: 30-170KHz(H)/ 48-144Hz(V)
sRGB
Flicker-free
Pixel Density: 92.56 PPI
Display Screen Coating: Anti-Glare, 3H, Haze 25%
Low Input Lag: Yes*
EasyRead
Adaptive sync (VRR)
Smart Crosshair
Smart MBR: 0.5 ms*
Smart MBR Sync
Shadow Boost
Connectivity
Signal Input: HDMI 1.4 x 1
Audio (In/Out): Headphone out
HDCP: HDCP 1.4 (HDMI)
Convenience
Plug & Play Compatibility: DDC/CI, Mac OS X,
sRGB, Windows 11 / 10
User convenience: Power On/Off, Menu/OK,
Input/Up, Game Settings/Down, SmartImage
game/Back
Other convenience: Kensington lock, VESA
mount (100x100mm), LowBlue Mode
Control software: Evnia Precision Center
Stand
Tilt: -5/20 degree
Power
Power supply: Internal, 100-240VAC, 50-60Hz
Off mode: 0.3 W (typ.)
On mode: 15.8 W (typ.)
Standby mode: 0.5 W (typ.)
Power LED indicator: Operation – White, Standby
mode- White (blinking)
Dimensions
Packaging in mm (WxHxD): 690 x 420 x 124 mm
Product without stand (mm): 544 x 321 x 51 mm
Product with stand(max height): 544 x 434 x 207 mm
Weight
Product with packaging (kg): 5.00 kg
Product with stand (kg): 2.88 kg
Product without stand (kg): 2.49 kg
Operating conditions
Altitude: Operation: +12,000ft (3,658m), Nonoperation: +40,000ft (12,192m)
Temperature range (operation): 0°C to 40 °C
MTBF: 50,000 (Excluded backlight) hour(s)
Relative humidity: 20%-80 %
Temperature range (storage): -20°C to 60 °C
Sustainability
Environmental and energy: RoHS
Recyclable packaging material: 100 %
Specific Substances: PVC / BFR free housing
Post consumer recycled plastics: 85%*
Compliance and standards
Regulatory Approvals: CB, CE Mark, ETL, CEC,
MEPS, PSB, PSE, BSMI, VCCI, UKCA, EMF, FCC,
ICES-003
Cabinet
Color: Charcoal
Finish: Textured
