Picture / Display
Panel Size: 23.8" / 60.5 cm
Aspect Ratio: 16:9
LCD Panel Type: IPS technology
Backlight Type: W-LED system
Pixel Pitch: 0.2832 x 0.2802 mm
Brightness: 300 cd/m²
Display Colors: 16.7M
Color Gamut (Typical): Adobe RGB 91.18% / DCI-P3 92.34% / sRGB 119.99% / NTSC 102.93%*
Contrast Ratio (Typical): 1500:1
SmartContrast: Mega Infinity DCR
Response Time (Typical): 4 ms (Gray to Gray)*
Viewing Angle: 178° (H) / 178° (V) @ C/R > 10
Picture Enhancement: SmartImage Game / SmartImage HDR
Maximum Resolution: 1920 x 1080 @ 144 Hz
Effective Viewing Area: 543.744 (H) x 302.616 (V) mm
Scanning Frequency: 30 KHz – 160 KHz (H) / 48 Hz – 144 Hz (V)
sRGB: Yes
Flicker-Free: Yes
Pixel Density: 90 PPI
LowBlue Mode: Yes
Display Screen Coating: Anti-Glare, 3H, Haze 25%
MPRT: 0.5 ms*
EasyRead: Yes
Adaptive Sync: Yes
HDR: HDR10
Connectivity
Signal Input: HDMI 1.4 x 1 / DP 1.4 x 1
Audio (In/Out): Audio out
HDCP: HDCP 1.4 (HDMI / DP)
Convenience
Plug & Play Compatibility: DDC/CI / Mac OS X / sRGB / Windows 11 / 10
User Convenience: Power On/Off / Menu / Brightness / Input / SmartImage Game / SmartImage HDR
OSD Languages: Brazil Portuguese / Czech / Dutch / English / Finnish / French / German / Greek / Hungarian / Italian / Japanese / Korean / Polish / Portuguese / Russian / Simplified Chinese / Spanish / Swedish / Traditional Chinese / Turkish / Ukrainian
Other Convenience: Kensington lock / VESA mount 100x100mm
Stand
Tilt: -5 / 20 degrees
Power
Power Supply: External, 100–240VAC, 50–60Hz
Off Mode: 0.3 W typ
On Mode: 14.4 W typ
Standby Mode: 0.5 W typ
Power LED Indicator: Operation – White / Standby – White blinking
Dimensions
Packaging (W x H x D): 635 x 420 x 123 mm
Product Without Stand: 562 x 325 x 32 mm
Product With Stand (Max Height): 562 x 419 x 180 mm
Weight
Product With Packaging: 4.57 kg
Product With Stand: 2.50 kg
Product Without Stand: 2.22 kg
Operating Conditions
Altitude: Operation +12,000 ft / Non-operation +40,000 ft
Temperature (Operation): 0 to 40 °C
Temperature (Storage): -20 to 60 °C
Relative Humidity: 20% – 80%
MTBF: 50,000 hrs (excluding backlight)
Sustainability
Environmental & Energy: RoHS
Recyclable Packaging Material: 100%
Compliance & Standards
Regulatory Approvals: CB / CE Mark / EAC / EAC ROHS / PSB / KC / KCC / BSMI / UKCA / EMF / FCC / ICES-003
Cabinet
Color: Black
Finish: Textured
