Picture / Display Connectivity
Panel Size: 23.8 inch / 60.5 cm Signal Input: VGA x1, HDMI 1.4 x1
Aspect Ratio: 16:9 Sync Input: Separate Sync
LCD Panel Type: IPS technology Audio In/Out: Audio-in, Audio out
Backlight Type: W-LED system HDCP: HDCP 1.4 (HDMI)
Pixel Pitch: 0.2745 x 0.2745 mm
Brightness: 300 cd/m² Convenience
Display Colors: 16.7 M Built-in Speakers: 2W x2
Color Gamut: Adobe RGB 84.49%, DCI-P3 81.39%, Plug & Play: DDC/CI, Mac OS, Windows 11 / 10
sRGB 102.66%, NTSC 89.36% User Controls: Power, Menu, Volume, Input, SmartImage
Contrast Ratio: 1500:1 OSD Languages: Multi-language
SmartContrast: Mega Infinity DCR Other: Kensington Lock, VESA 100 x 100 mm
Response Time: 4 ms (GtG), 1 ms MPRT EasyRead: Yes
Viewing Angle: 178° / 178° Adaptive Sync: Yes
Picture Enhancement: SmartImage
Maximum Resolution: 1920 x 1080 @ 120 Hz Stand
Effective Viewing Area: 527.04 x 296.46 mm Tilt: -5° / +20°
Scanning Frequency:
VGA: 30–85 kHz / 48–75 Hz Power
HDMI: 30–140 kHz / 48–120 Hz Power Supply: Internal, 100–240 VAC
sRGB: Yes On Mode: 14 W (typ.)
SoftBlue: Yes Standby Mode: 0.5 W (typ.)
Flicker-Free: Yes Off Mode: 0.3 W (typ.)
Pixel Density: 93 PPI Power LED: White / White blinking
LowBlue Mode: Yes
Screen Coating: Anti-Glare, 3H, Haze 25% Dimensions / Weight
Packaging: 610 x 370 x 124 mm Product With Stand: 2.92 kg
Product Without Stand: 542 x 316 x 45 mm Product Without Stand: 2.57 kg
Product With Stand: 542 x 417 x 180 mm Product With Packaging: 4.68 kg
Operating Conditions Sustainability
Altitude: Up to 12,000 ft (operation) Environmental: RoHS
Temperature (Operation): 0°C to 40°C Recyclable Packaging: 100%
Humidity: 20%–80% PVC / BFR Free Housing
Storage Temperature: -20°C to 60°C
MTBF: 50,000 hrs
Compliance / Cabinet
Regulatory: CB, CE, FCC, UKCA, etc.
Cabinet Color: White
Finish: Textured
