Model Configurations
| PERFORMANCE | |
| Processor |
Intel® Core™ Ultra 7 155U, 12C (2P + 8E + 2LPE) / 14T, Max Turbo up to 4.8GHz, 12MB |
| AI PC Category |
AI PC |
| NPU |
Integrated Intel® AI Boost, up to 11 TOPS |
| Graphics |
Integrated Intel® Graphics |
| Chipset |
Intel® SoC Platform |
| Memory |
16GB Soldered LPDDR5x-6400 |
| Memory Slots |
Memory soldered to systemboard, no slots, 8-channel |
| Max Memory |
16GB soldered memory, not upgradable |
| Storage |
512GB SSD M.2 2280 PCIe® 4.0×4 Performance NVMe® Opal 2.0 |
| Storage Support |
One drive, up to 2TB M.2 2280 SSD |
| Storage Slot |
One M.2 2280 PCIe® 4.0 x4 slot |
| Card Reader |
None |
| Optical |
None |
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3306 codec |
| Speakers |
Stereo speakers, 2W x2, Dolby Atmos® |
| Camera |
FHD 1080p + IR Discrete with Privacy Shutter |
| Microphone |
2x, Array |
| Battery |
57Wh |
| Power Adapter |
65W USB-C® Slim (3-pin) |
| DESIGN | |
| Display |
14" WUXGA (1920×1200) IPS 400nits Anti-glare, 100% sRGB, 60Hz, Low Power |
| Touchscreen |
None |
| Keyboard |
Backlit, English |
| Touchpad |
Trackpad |
| Case Color |
Black, Paint |
| Case Material |
Carbon Fiber (Top), Aluminium (Bottom) |
| Pen |
Pen Not Supported |
| Dimensions (WxDxH) |
312.80 x 214.75 x 14.96 mm (12.31 x 8.45 x 0.59 inches) |
| Weight |
Starting at 1.08 kg (2.37 lbs) |
| SOFTWARE | |
| Operating System |
Windows® 11 Pro, English |
| Bundled Software |
Intel® Connectivity Performance Suite |
| CONNECTIVITY | |
| WLAN + Bluetooth |
Intel® Wi-Fi® 6E AX211, 802.11ax 2×2 + BT5.3 |
| WWAN |
WWAN Upgradable to 4G or 5G |
| SIM Card |
None |
| Ethernet |
No Onboard Ethernet |
| NFC |
None |
| Standard Ports |
|
| Optional Ports (configured) |
1x Nano-SIM Card Slot |
| Docking |
Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad X1 Carbon Gen 12 |
| SECURITY & PRIVACY | |
| Smart Card Reader |
None |
| Security Chip |
Discrete TPM 2.0 Enabled |
| Fingerprint Reader |
Touch Style, Match-on-Chip, in Keyboard Key |
| Physical Locks |
Kensington® Nano Security Slot™, 2.5 x 6 mm |
| Other Security |
|
| MANAGEABILITY | |
| System Management |
Non-vPro® |
| SERVICE | |
| Base Warranty |
1-year, Courier or Carry-in |
| Included Upgrade |
3Y Accidental Damage Protection Add On, 3Y Sealed Battery Add On, 3Y Premier Support Upgrade from 1Y Courier/Carry-in |
| ACCESSORIES | |
| Bundled Accessories |
None |
| CERTIFICATIONS | |
| Green Certifications |
|
| Other Certifications |
|
| Mil-Spec Test |
MIL-STD-810H military test passed |
