| SPECIFICATIONS | |
| Product Name | MWE Bronze 550 V3 230V |
| Item Code | MPE-5501-ACABW-3B |
| ATX Version | ATX 12V Ver. 3.1 |
| PFC | Active PFC |
| Input Voltage | 200 – 240V |
| Input Current | 5A |
| Input Frequency | 50 – 60Hz |
| Dimensions (L x W x H) | 140 x 150 x 86mm |
| Fan Size | 120 mm |
| Fan Bearing | HDB |
| Efficiency | ≥ 88% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Bronze |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0 ~ 40℃ |
| Power Good Signal | 100 – 150ms |
| Hold Up Time | ≥ 16ms |
| MTBF | >100,000 hours @ 25℃ ambient |
| Protections | UVP / OVP / OPP / OTP / SCP |
| Regulatory | TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, |
| ATX 24 Pin | KC (based on region's request.) |
| Connectors | x1 = 1x (500mm) |
| EPS 8Pin / 4+4 Pin | x2 = 1x (550+120mm) |
| SATA | x6 = 2x (400+150+150mm) |
| Peripheral 4 Pin | x3 = 1x (400+150+150mm) |
| PCI-e 6+2 Pin | x2 = 1x (500+120mm) |
