Explosive pace for intense gaming

Discover the powerful performance with PCIe 4.0 and experience blistering speeds to beat the competition. The thermal regulation of the Samsung controller offers high energy efficiency with consistently high speeds and performance.¹

PCIe at blazing speeds

Featuring 40% and 55% faster random read and write speeds compared to the 980 PRO, up to 1400K / 1550K IOPS and sequential read/write speeds up to 7450 / 6900MB/s.² ³ ?

Groundbreaking energy efficiency

Higher performance often consumes more power. Not with the 990 PRO. Experience low power consumption with over 50% improved performance per watt over the previous model.?

The performance maker

Because a performance improvement of more than 55% over the previous model, this enables faster loading processes for a more authentic gaming experience for the PlayStation 5 and PC games with Direct Storage function.? ?

Smart temperature regulation

The nickel-plated controller and state-of-the-art thermal control algorithm regulate heat and allowing for unrestricted performance. The heat-spreader label controls the heat of the NAND chip, while the Dynamic Thermal Guard technology regulates temperatures.

Samsung Magician software

The user-friendly software solution helps you to always keep an eye on your SSD. With it, you can keep your drive up-to-date with updates, monitor status parameters and speed, and even optimise performance.

General Feature

• ApplicationClient PCs, Game Consoles
•
• Capacity1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
•
• Form FactorM.2 (2280)
•
• InterfacePCIe Gen 4.0 x4, NVMe 2.0
•
• Dimension (Pack: WxHxD)80 x 22 x 2.3 mm
•
• WeightMax 9.0g Weight
•
• Storage MemorySamsung V-NAND 3-bit MLC
•
• ControllerSamsung in-house Controller
•
• Cache MemorySamsung 1GB Low Power DDR4 SDRAM

Special Feature

• TRIM SupportSupported
•
• S.M.A.R.T SupportSupported
•
• GC (Garbage Collection)Auto Garbage Collection Algorithm
•
• Encryption SupportAES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
•
• WWN SupportNot supported
•
• Device Sleep Mode SupportYes

Performance

• Sequential ReadUp to 7,450 MB/s * Performance may vary based on system hardware & configuration
•
• Sequential WriteUp to 6,900 MB/s * Performance may vary based on system hardware & configuration
•
• Random Read (4KB, QD32)Up to 1,200,000 IOPS * Performance may vary based on system hardware & configuration
•
• Random Write (4KB, QD32)Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration
•
• Random Read (4KB, QD1)Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
•
• Random Write (4KB, QD1)Up to 80,000 IOPS * Performance may vary based on system hardware & configuration

Environment

• Average Power Consumption (system level)*Average: 5.4 W*Maximum: 7.8 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
•
• Power consumption (Idle)Max. 50 mW * Actual power consumption may vary depending on system hardware & configuration
•
• Allowable Voltage3.3 V ± 5 % Allowable voltage
•
• Reliability (MTBF)1.5 Million Hours Reliability (MTBF)
•
• Operating Temperature0 – 70 ? Operating Temperature
•
• Shock1,500 G & 0.5 ms (Half sine)

Accessories

• Installation KitNot Available

Software

• Management SWMagician Software for SSD management

Warranty

• 5-Year Limited Warranty or 600 TBW Limited Warranty
