Picture/Display
Panel Size :27 inch / 68.6 cm
Aspect ratio : 16:9
LCD panel type : IPS technology
Backlight type : W-LED system
Pixel pitch : 0.3114 x 0.3114 mm
Brightness : 250 cd/m²
Display colors : 16.7 M
Contrast ratio (typical) : 1000:1
SmartContrast : Mega Infinity DCR
Response time (typical) : 4 ms (Gray to Gray)*
Viewing angle
- 178º (H) / 178º (V)
- @ C/R > 10
Picture enhancement : SmartImage
Maximum resolution : 1920 x 1080 @ 120Hz (HDMI)
Effective viewing area : 597.888 (H) x 336.312 (V)
Scanning Frequency :
VGA: 30 KHz – 85 KHz (H) / 48 Hz – 60 Hz (V); HDMI: 30 KHz – 140 KHz (H) / 48 Hz – 120 Hz (V)
sRGB : Yes
Flicker-free : Yes
Pixel Density : 81.59 PPI
LowBlue Mode : Yes
Display Screen Coating : Anti-Glare, 3H, Haze 25%
MPRT : 1 ms
EasyRead : Yes
Adaptive sync : Yes
Connectivity
Signal Input L: VGA x 1, HDMI 1.4 x 1
Sync Input
- Separate Sync
- Sync on Green
HDCP : HDCP 1.4 (HDMI)
Other convenience
- Kensington lock
- VESA mount (100x100mm)
- Stand
Tilt : -5/20 degreePower
Power supply- External
- 100-240VAC, 50-60Hz
-
Off mode : 0.3 W (typ.)On mode : 17.6 W (typ.)
Standby mode : 0.5 W (typ.)
Power LED indicator
- Operation – White
- Standby mode- White (blinking)
- Dimensions
Packaging in mm (WxHxD) : 690 x 480 x124 mmProduct without stand (mm) : 614 x 363 x 34 mm
Product with stand(max height) : 614 x 457 x 200 mm
Weight
Product with packaging (kg) : 5.48 kgProduct with stand (kg) : 3.06 kg
Product without stand (kg) : 2.70 kg
Operating conditions
Altitude : Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)Temperature range (operation) : 0 to 40 °C
MTBF : 50,000 hrs (excluding backlight) hour(s)
Relative humidity : 20%-80 %
Temperature range (storage) : -20 to 60 °C
Sustainability
Environmental and energy : RoHSRecyclable packaging material : 100 %
Specific Substances : Mercury free
Cabinet
Color : BlackFinish : Textured
