Technical Specifications
Connectivity

Signal Input
HDMI 2.0 x 2, DisplayPort 1.4 x 1
Sync Input
Separate Sync
Audio (In/Out)
Audio out
HDCP
HDCP 1.4 (HDMI / DP), HDCP 2.2 (HDMI / DP)
Picture/Display

Panel Size
23.8 inch / 60.5 cm
Aspect ratio
16:9
LCD panel type
IPS technology
Backlight type
W-LED system
Pixel pitch
0.2745 x 0.2745 mm
Brightness
300  cd/m²
Display colors
16.7 M
Color gamut (typical)
DCI-P3 : 93% , sRGB : 126% , NTSC : 113% , Adobe RGB 110%*
Contrast ratio (typical)
1000:1
SmartContrast
Mega Infinity DCR
Viewing angle
178° (H) / 170° (V)
@ C/R > 10
Picture enhancement
SmartImage game
SmartResponse
1 ms (Gray to Gray)*
Maximum resolution
1920×1080 @ 180 Hz (HDMI/DP)
Effective viewing area
527.04 (H) x 296.46 (V)
Scanning Frequency
30 – 200 kHz (H) / 48 – 180 Hz (V)
sRGB
Yes
Flicker-free
Yes
Pixel Density
93 PPI
LowBlue Mode
Yes
Display Screen Coating
Anti-Glare, 3H, Haze 25%
Low Input Lag
Yes
EasyRead
Yes
HDR
HDR 10 supported
Smart MBR
0.5 ms*
Convenience

Built-in Speakers
2 W x 2
Plug & Play Compatibility
DDC/CI
Mac OS X
sRGB
Windows 11 / 10
User convenience
Power On/Off
Menu/OK
Input/Up
Game Settings/Down
SmartImage game/Back
OSD Languages
Czech
Dutch
English
French
German
Hungarian
Italian
Japanese
Korean
Polish
Portuguese
Russian
Simplified Chinese
Spanish
Swedish
Traditional Chinese
Turkish
Greek
Finnish
Brazil Portuguese
Ukrainian
Other convenience
Kensington lock
VESA mount (100x100mm)
Stand

Swivel
-5/20  degree
Power

Power supply
Internal
100-240VAC, 50-60Hz
Off mode
0.3 W (typ.)
On mode
18.7 W (typ.)
Standby mode
0.5 W (typ.)
Power LED indicator
Operation – White
Standby mode- White (blinking)
Energy Label Class
E
Dimensions

Packaging in mm (WxHxD)
610 x 395 x 126  mm
Product without stand (mm)
540 x 325 x 55  mm
Product with stand(max height)
540 x 433 x 195  mm
Weight

Product with packaging (kg)
5.51  kg
Product with stand (kg)
3.38  kg
Product without stand (kg)
2.77  kg
Operating conditions

Altitude
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
Temperature range (operation)
0°C to 40  °C
MTBF
50,000 (Excluded backlight)  hour(s)
Relative humidity
20%-80  %
Temperature range (storage)
-20°C to 60  °C
Sustainability

Environmental and energy
RoHS
Recyclable packaging material
100  %
Post consumer recycled plastics
85%*
Compliance and standards

Regulatory Approvals
CB
CE Mark
TUV/ISO9241-307
TUV-BAUART
EAC
BSMI
EMF
FCC
ICES-003
MEPS
PSB
E-standby
KC
UKCA
Cabinet

Color
Charcoal
Finish
Textured
