• Power Supply: VDD = 1.2V Typical
• VDDQ = 1.2V Typical
• VPP = 2.5V Typical
• VDDSPD = 2.2V to 3.6V
• On-Die termination (ODT)
• 16 internal banks; 4 groups of 4 banks each
• Bi-Directional Differential Data Strobe
• 8 bit pre-fetch
• Burst Length (BL) switch on-the-fly BL8 or BC4(Burst Chop)
• Height 1.66” (42.2mm), w/heatsink
10 in stock
FACTORY TIMING PARAMETERS
• Default (JEDEC): DDR4-2400 CL17-17-17 @1.2V
• XMP Profile #1: DDR4-3200 CL16-18-18 @1.35V
• XMP Profile #2: DDR4-3000 CL15-17-17 @1.35V
CL(IDD) Row Cycle Time (tRCmin) Refresh to Active/Refresh Command Time (tRFCmin) Row Active Time (tRASmin) UL Rating Operating Temperature Storage Temperature 17 cycles 45.75ns(min.) 350ns(min.) 32ns(min.) 94 V – 0 0o C to +70o C -40o C to +85o C
| Weight | 0.5 kg |
|---|---|
| Dimensions | 10 × 10 × 4 cm |
